Name: Grass and Non-Vegetated Areas

Display Field: Stage

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;font-size:12pt"><DIV><P><SPAN>Diamond Head used Bellingham's 2013 vegetation model to identify grass and non-vegetated areas that my have the potential to support tree planting in the future. Roads, parks facilities (e.g. sports fields, active use areas, etc.), impervious surfaces, buildings, and the 2018 canopy layer were erased from the layer to update it to 2018 conditions and remove areas that would not have potential to support tree planting. The grass and non-vegetated areas were then grouped by ownership and management class. Finally, Diamond Head generated course estimates of the number of trees that could potentially occupy these spaces if planted. Estimates for number of potential trees were calculated by management unit and tree soil area (assuming 24 inch depth) based on the Bellingham's City Center Street Design Standards which recommend soil areas for: 1. Large trees (50 ft mature canopy) recommend soil area of 750 sq ft; 2. Medium/large trees (40 ft mature canopy) recommend soil area of 600 sq ft; 3. Medium trees (35 ft mature canopy) recommend soil area of 500 sq ft; 4. Small trees (20 ft mature canopy) recommend soil area of 300 sq ft. The number of trees that could potentially be planted based on these recommended soil areas was calculated from largest to smallest meaning that all sites larger than 750 ft2 were assumed to be large trees only, then sites between 600 ft2 and 749 ft2 were medium/large trees only and so on until only small tree sites remained. Polygons smaller than 300 ft2 were not considered plantable. This analysis provides an estimate of the relative capacity of different land uses to support tree planting and potential canopy gain. While these areas provide a coarse relative estimate of the potentially available planting areas in the City, other considerations including site constraints and usage conflicts and future land use would need to be considered to refine these areas into actionable planting opportunities.</SPAN></P></DIV></DIV>

Copyright Text: City of Bellingham, Diamond Head Consulting

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.36439894773E7
YMin: 6223353.023000002
XMax: -1.36240792743E7
YMax: 6244554.245399997
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [137, 205, 102, 255]
Outline:
Style: esriSLSSolid
Color: [56, 168, 0, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Stage ( type: esriFieldTypeString, alias: Stage, length: 100 )
• Restoration ( type: esriFieldTypeString, alias: Restoration, length: 50 )
• Riparian_Forests ( type: esriFieldTypeString, alias: Riparian Forests, length: 255 )
• Acreage ( type: esriFieldTypeDouble, alias: Acreage )
• Classification ( type: esriFieldTypeString, alias: Classification, length: 255 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )
• FeatureLengthFeet ( type: esriFieldTypeDouble, alias: FeatureLengthFeet )
• FeatureAreaFeet ( type: esriFieldTypeDouble, alias: Area (ft) )

Supported Operations:   Query   Query Attachments   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
